ELM1 Series Servo Motor - ELM1H-0400MA60E (With Brake)

The Leadshine ELM1H-0400MA60E is a compact and high-precision 400W AC servo motor with built-in electromagnetic brake, designed for CNC machines, automation systems, robotics, pick-and-place equipment, packaging machines, and linear motion applications. Its integrated holding brake makes it especially suitable for vertical axes (Z-axis) and applications where load holding is required during power-off conditions.

These servo motors use rare earth neodymium-iron-boron permanent magnet rotors, provide features of high torque density, high peak torques, low noise, low temperature rising, lower current consumption. The motors power range from 50W to 1000W, frame size range from 40mm to 80mm.

Technical Specifications

Mechanical

Speed-Torque Curve

⭐ With Electromagnetic Brake

Why Choose the Brake Version?

The ELM1H-0400MA60E comes with an integrated electromagnetic holding brake, which helps prevent unwanted movement when power is removed.

Ideal For:

• CNC Router Z-Axis
• CNC Plasma Z-Axis
• Vertical Ball Screw Actuators
• Lifting Mechanisms
• Pick & Place Machines
• Robotics Applications
• Automation Systems with Vertical Loads

Benefits of Brake Motor

✔ Holds position during power loss
✔ Prevents axis dropping under gravity
✔ Improves machine safety
✔ Protects tooling and workpieces
✔ Suitable for vertical motion systems

Note: The brake is designed for load holding and positioning retention. It is not intended as a dynamic stopping brake during normal machine operation.

Data Sheet - Click Here

3D File in Step Format - Click Here

Compatible Servo Drives

The ELM1H-0400MA60E servo motor is compatible with:

• Leadshine EL7-RS400P Servo Drive
• Leadshine EL7-RS750P Servo Drive
• Leadshine EL7-RS1000P Servo Drive

Proper encoder and motor cable sets are required for installation.

ELM1H-0400MA60E vs ELM1H-0400MA60F

Feature	ELM1H-0400MA60E	ELM1H-0400MA60F
Rated Power	400W	400W
Rated Torque	1.27 N·m	1.27 N·m
Rated Speed	3000 RPM	3000 RPM
Encoder	23-bit	23-bit
Brake	Yes	No
Recommended Use	Vertical Axes	Horizontal Axes

ELM1H-0400MA60E is the preferred choice when load holding and safety during power-off conditions are required.

Looking for a servo motor with brake for CNC Z-axis or vertical actuator applications?

The Leadshine ELM1H-0400MA60E provides high precision motion control combined with secure load holding, making it an excellent choice for demanding industrial automation systems.
